Automatic Steel Coil Wrapping Machine With Adjustable Take Up Arm Φ30-65mm

Steel Coil Wrapping Machine features

1. PLC and HMI control system for automatic operation.
2. Two working modes: automatic and manual.
3. Tension control for pipe feed for tight winding.
4. The parameters can be set in the PLC program.
5. Calculate the length of the pipe and automatically cut the pipe.
6. Automatic winding system.
7. Automatic alarm system when a fault occurs.
8. The position of the pipe is automatically detected by the sensor.
9. The speed can be adjusted by the frequency converter.
10. Pipe feeders are used with automatic displacers.
11. Winding the pipe coil in an orderly manner.
12. The pneumatic pusher discharges the tube coil.
13. Hydraulic cutting machine for cutting powerful pipes

Steel Coil Wrapping Machine Introduction

QTIT automatic coiling and strapping machines are CE compliant and are designed with the latest technology and industrial design standards. We offer you packaging solutions for the pipeline industry.

Steel Coil Wrapping Machine specifications

The standard configuration is listed below. For other configurations, please contact our sales representative.

The machine should be installed on a flat, hard floor with a load of more than 1 ton / square meter.

Packaging process:

A. Pipe from the extruder/spool through the tensioner and counter

B. Automatically send the pipeline to the take-up station.

C. The pipe head is clamped and rotated for winding

D. Automatic layering and coil making.

E. The pipe is automatically cut when the pipe length reaches the set value.

F. Automatic film feeding and packaging.

G. Packaging completed and cut the movie

H. Introduce the wound coil.

Steel Coil Wrapping Machine Technical data:
